特征
产品优势
高效的燃油供应系统和进气系统使燃油和空气混合得更充分，完全燃烧，污染物排放更少。
1.舷外机小，重量轻，体积小，便于运输和存放。
2.结构简单，工艺成熟，性能优良。
3.模块化电子点火，启动方便，维护简单。
4.采用船用级防腐材料，增强耐用性。
规格
| Model | T9.8 | |
| Specs Options | T9.8BMS/T9.8BML | |
| Transom Height | 15in./20in. | |
| Dry Weight | 26-27Kg | |
| Max. RPM range | 5000～6000r/min | |
| Max. outpower | 7.2kW（9.8HP）@5000r/min | |
| Idling RPM range | 1150～1250 r/min | |
| Engine Type | L2 Reed Valve | |
| Displacement | 169cc | |
| Bore X Stroke | 55.0×43 mm | |
| Ignition Timing | CDI | |
| Steering System | Tiller handle | |
| Starting System | Manual start | |
| Gear Shift | F-N-R | |
| Gear Ratio | 2.08 | |
| Trim &Tilt | Manual | |
| Fuel Tank Capacity | 12L | |
| Max. Fuel Consumption | 5.1L/h | |
| Gear Oil Capacity | 320cc | |
| Mixing Ratio(Fuel:Oil) | 50:1 | |
| Propeller | 3-8.3" | |
Parameter description:
| ||
